Low Side Gate Driver With Current Sense

The drv8705s q1 provide an array of protection features to ensure robust system operation.

Low side gate driver with current sense.

Max operating range doubler charge pump for 100 pwm half bridge and h bridge control modes. 40 c to 125 c ta smart gate driver 4 9 v to 37 v 40 v abs. These include under and over voltage monitors for the power supply and charge pump vds overcurrent and vgs gate fault monitors for the external mosfet and. On semiconductor s high voltage process and common mode noise canceling technique provide stable operation of high drivers under high dv dt noise circumstances.

The fan7191 f085 is a monolithic high and low side gate driver ic which can drive high speed mosfets and igbts that operate up to 600v. A shunt amplifier provides low side current sensing to continuously measure motor current. Temperature grade 1. Many gate drivers have a logic low input voltage of only 0 8v which could be compromised by voltage drop across the sense resistor.

However if i connect the gate driver s ground to high side of the sense resistor that means that the reference for the input to the driver will move with source current. Featured low side driver devices ucc27511a single channel high speed low side gate driver with 4 a peak source and 8 a peak sink. Drv8705 q1 automotive h bridge smart gate driver with low side current sense amplifier 1 1 features 1 aec q100 qualified for automotive applications. Our low side gate drivers feature high drive current low propagation delay negative voltage handling and under voltage lockout uvlo to maximize your system s performance and reliability regardless of application.
